ENGINE
Engine Model | A2300T11 |
Aspiration | Turbo |
Emissions Standards | Tier 4 |
Engine Gross Power | 55 hp (41.0 kW) |
PTO Power | 44 hp (32.8 kW) |
No. of Cylinders | 4 |
Displacement | 139.5 cu.in (2,286 cc) |
Rated Revolution | 2600 RPM |
Fuel Tank Capacity | 11.8 gal (45 L) |
Air Cleaner | Dry Element |
Alternator – 12 Volt amp | 70 |
DRIVETRAIN
Transmission | Synchromesh |
Forward/Reverse Method | Synchroshuttle |
4 Wheel Drive | 2WD/4WD |
No. of Traveling Speeds | 12F / 12R(3 Range) |
Forward Traveling Speed @ 2600 | 19 mph (30.5 km/h) |
Reverse Traveling Speed @ 2600 | 18.1 mph (29.2 km/h) |
Clutch | Dry Single Type (N/A) |
Brake | Wet, Multi-disc |
Differential Lock | Standard |
Cruise Control | No |
HYDRAULICS
Steering | Hydrostatic Power Steering |
Total Hydraulic Flow (POWER STEERING + Implement) | 14.3 (4.4+9.9) gpm /54.2 (16.8+37.4) lpm |
Lift Control Type | Position |
Joystick Valve | Standard |
Rear Remote (Port) | 4 Port |
3 POINT HITCH
3 Point Hitch | CAT I |
Lift capacity at lift link ends | 3,306 lbs (1,500 kg) |
3Point Hitch Lift Capacity @24″ behind lift point | 2,425 lbs (1,100 kg) |
PTO
Rear (Mid) PTO Speed | 584 / 791 RPM |
Rear PTO Type | Independent |
Clutch | Wet, Multi-disc |
TIRES
AG Front | 9.5 – 16 |
AG Rear | 13.6 – 26 |
Turf Front | 27 x 8.5-15/29 x 12.5-15 |
AG Rear | 41 x 14-20/ 44 x 18-20 |
Ind. Front | 12 – 16.5 |
AG Rear | 17.5L x 24 |
DIMENSIONS
Wheelbase | 71.1 in (1,806 mm) |
Overall Length (W/ 3PT) | 127.4 in (3,236 mm) |
Min.Overall Width | 64.9 in (1,650 mm) |
Overall Height (W/ ROPS) | 97 in (2,463 mm) |
Ground Clearance (4WD) | 15.5 in (394 mm) |
Min.Turning Radius (W/ Brake) | 9.18 ift (2.8 m) |
Weight (W/O Front Weights) | 4,349 (1,973 kg) |
